55inch Smart Board Interactive Flat Panel , 4K Interactive Panel For Education

Ask Lasest Price
Brand Name :	JCVISION
Model Number :	JC-T55K-IR
Certification :	CE, Rohs, FCC
Price :	Negotiable
Payment Terms :	T/T
Supply Ability :	1000 Unit/Units per Month
Delivery Time :	5-8 work days

Add to Cart

Product Details
Company Profile

55inch Smart Board Interactive Flat Panel , 4K Interactive Panel For Education

JCVISION 4K 55inch Interactive Flat Panel Display For Smart Education And Business Conference

Description

1) Aluminum alloy frame with sandblasted and anodized surface and iron shell back cover for active heat dissipation.
2)4mm physically tempered storm-proof glass; enhanced visual effect and improved touch experience.
3) High-speed 20-point touch writing experience, better roundness and faster writing speed.
5)Use of international standard OPS slot, integrated plug-in design, easy to upgrade and maintain, no external visible computer module connection cable, beautiful body.
6) Front expansion ports: 1 PC-USB, 1 full channel-USB, 1 HDMI input, 1 TOUCH USB to facilitate the use of external devices
7) speaker out of the sound front, to prevent the embedded environment caused by the sound effect deterioration.
8) child lock function, through the setting can be blocked button function.
9)Support gesture pull up menu, menu can quickly adjust the brightness sound, and switch the signal source
10)Front button one key start, can turn on and off the screen and host at the same time, simple and convenient operation
11) Android 8.0 system support, multi-themed system settings at any time to switch, boot LOGO settings customization and other functions
12)The system comes with the functions of screen casting, electronic whiteboard, annotation, etc.

Specification

Technical parameter
Display	Screen size	55 inch	Specification	Product size	1257.7745.282.2MM	No external installation media
	Brand	BOE / China star		Size including bracket	1257.7745.2103.5MM	distance between holes	400*400MM
	Backlight	DLED straight-down		Wall mounting dimensions	1277.7765.2103.5MM	Installation principles	widening 20mm on two sides
	Display type	2D		packaging size	1366.6185891.5mm	Package	kraft carton
	pitch	0.372 x 0.372mm		Net Weight/ Gross Weight	23.5/30.5KG	Net weight(product weight) Gross weight(including accessories and package)
	Display area	1208.6*677.9MM		Installation	Wall mounting (standard)
	Ratio	16:9		Front interface	USB1(OPS input),USB2(TV board input)
	Resolution	3840x 2160 UHD		storage environment	storage temp.:-20℃~60℃; storage humidity:10%RH~90%RH
	Brightness	350cd/㎡		working environment	working temp. :-10℃~55℃；working humidity:10%RH~90%RH
	Contrast	1400:1(Typ.)		life span	>=50000hours
	Color	8 bit/16.7 Million	Power	Working voltage	110~240V/50~60Hz	Power switch/position		Yes/Back side
	Viewing angle	178°,178°		consumption	about 120W	Power Supply Type/Mode		Three-pin power supply/fixed
	Refresh rate	60Hz		Standby power consumption	≦0.5W	Power interface		Pin socket
	Response time	8ms	Mainboard	Model	DZ-B-84P-VB-V1.1
	Accompaniment power	8Ω8W x2		Operating system	Android6.0
				Configuration	RAM 1G DDR3,Storage: 8G wifi 2.4GHZ
Touch	Touch type	IR		Processor	MSD658
	Touch point	20 points touch		Input port	RJ45, Touch usb, RS232, YPBPR IN, AV IN, VGA IN, VGA AUDIO IN, 1*HDMI in, USB2.0, RF-IN, SD card, MIC IN;
	Touch Embedding	Side-Embedded
	Touch drive mode	HID drive-free		output port	SPDIF OUT, EARPHONE, AV OUT;
	Writing Surface Materials	4mm tempered glass		Audio	MPEG1/2 layer I/II,AC-3(need customization),AAC-Lc,WMA…
	sensing method	Finger or other non-transparent touch sensitive media		video	MPEG-2/4,AVS,H.264,H.265,TS,Realmedia…
	Resolution	4096X4096		Image	Support JPG, BMP, PNG and other image formats to view and rotate / slide show / zoom in on images
	Touch System Communication Port	USB 2.0
	functions & calibration	automatic software detection
	Response time	<8ms
	touch frequency	No limits
	Scanning speed	100Hz/second
	Cursor speed	125P/S
	Touch Accuracy	≦2mm
	Installation & maintenance	Rear/ side-mounted maintenance type	Remarks	Standard configuration: I3 Gen 2 - 4G-128G solid state Accessories: wall bracket, expansion screws, stylus, warranty card, certificate of conformity, manual, remote control. Optional accessories: mobile stand, telescopic whip
	Operating systems	XP/Win7/ Win10/ LINUX/ Android
