Feature:
Rounded corner design, slim, elegant and fashion
Aluminum bezel, wiredrawing treatment
Theft-proof lock for protecting memory card
AG or AR glass for protecting the LCD screen
Standard VESA holes and console holes for wall mounting
Optional media controller board
Single version support SD card, USB memory
Network version support internet and 3G net, can be group managed
via net
Support all video, audio and picture formats
Support horizontal or vertical screen play
Optional touchscreen
Available Sizes:19" 22" 26" 32" 43" 49" 55" 65" 84"
Specification:
| Model No. | JC-WM650NT |
| LCD panel | Screen Size | 65'' |
| Aspect ratio | 16:9 |
| Pixel numbers | 1920*1080 |
| Brightness | 450 cd/m2 |
| Contrast Ratio | 5000:1 |
| Viewing Angle | 178° (H)/178° (V) |
| Colors | 16.7 M |
| Single version | Interface | USB, SD card |
| Plug in SD card / U-disk to play the advertisement |
| Android version | CPU | RK3188CPU,quad core, 1.5Ghz(RK3288/RK3399 CPU option) |
| RAM | DDR3 2GB , 4GB option |
| Nand flash | 8GB, 16GB option |
| Operation system | Android 5.1 OS |
| Interface | USB2.0/RJ45 /VGA/HDMI etc. |
| Network | Support Wlan/Wifi/RJ45, Built-in 3G module option |
| Windows version | CPU/mainboard | Intel i3CPU ,Dual core,2.0GHz (Intel i3,i7CPU option) |
| Memory(RAM) | 2GB DDR3 |
| Hard disk(ROM) | 500G |
| Operation system | Windows7/8 |
| Interface | USB2.0/RJ45 /HDMI/VGA etc. |
| Network | Support Wlan/Wifi/RJ45, Built-in 3G module option |
| Speakers | Built-in 2*5W |
| Display formats | Support formats | Video: MPEG1, MEPG3, MEPG4, AVI, MP3 |
| Photo: JPG, JEPG, BMP, PNG, GIF |
| Display mode | Support full screen / multi-screen |
| Videos, photos, scroll texts auto detect, play and loop |
| Operating condition | Temperature | 0°C to 50°C (Operating) |
| -10°C to 60°C (Storage ) |
| Humidity | 10% RH to 90% RH (Operating) |
| 10% RH to 90% RH (Storage) |
| Power | Input Voltage | 100-240V AC |
| Operation | 200 watt |
| Weight | N.W./G.W. | 55 Kgs |
| Mount/installation | VESA 100/200 mm |
| Protection | AG/AR/vandal-proof glass option |
| Touchscreen | Infrared/Capacitive touch screen option |
Customize Part:
1.Logo 2.Color 3.Size 4.Designs
5.Optional extra functions:
---Printer
---Webcam
---2D bar code reader
---Credit card reader Etc.
Option 1: Standalone version:
It is built-in media player, it support inserting USB or SD card to
auto loop play video and picture in the card. It support preset
time to pay.
Option 2: Network version:
It built-in Android OS or Winows 7/10 OS PC, it support installing
Remote Management Advertising software, it support WIFI, LAN, 3G
network;
